Description

Pioneer GM-D8701

Mono 1600W Class-D Car Amp, with Bass Boost Remote

• 1,600 Watts Max Power
• Compact Design for Versatile Installation Options
• Wired Bass Boost Remote and Variable Bass Control
• 1 Ω Stable

Technical Specs

• NUMBER OF CHANNELS: MONO
• MAX. WATTAGE (4 Ω): 600 W X 1
• MAX. WATTAGE (2 Ω): 1,000 W X 1
• MAX. WATTAGE (1 Ω): 1,600 W X 1
• WATTAGE RMS (4 Ω <= 1%THD+N): 300 W X 1
• WATTAGE RMS (2 Ω <= 1%THD+N): 500 W X 1
• WATTAGE RMS (1 Ω <= 1%THD+N): 800 W X 1
• FREQUENCY RESPONSE: 10 HZ TO 240 HZ
• TOTAL HARMONIC DISTORTION (1KHZ, 4 Ω): < 0.5% (100 HZ)
• SIGNAL-TO-NOISE RATIO (IHF-A WEIGHTED): > 100 DB
• DIMENSIONS (W X H X D): 265 MM X 60 MM X 200 MM
